Aberdeen Proving Ground, Md., USA - December 27, 2014 - For the first time, the U.S. Army lofted a blimp equipped with a new cruise-missile and drone-fighting radar system high above rural Maryland. The system, made by Raytheon Company (NYSE: RTN) and known as JLENS, consists of two helium-filled aerostats, or tethered blimps, that float 10,000 feet above the ground and carry powerful radars. The second aerostat is scheduled to go aloft in early 2015. Following a series of additional tests, it will also be turned over to the Soldiers, who will conduct an operational exercise with JLENS. During the exercise, information from JLENS will be used by NORAD, the U.S.-Canadian organization charged with aerospace warning, aerospace control and maritime warning for North America. JLENS has demonstrated its ability to integrate with defensive systems and help Patriot, AMRAAM, NASAMS and Standard Missile 6 intercept cruise missile targets.
 |
JLENS has demonstrated its ability to integrate with defensive systems and help Patriot, AMRAAM, NASAMS and Standard Missile 6 intercept cruise missile targets.
Courtesy of Raytheon |
|
Aberdeen Proving Ground, Md., USA - December 27, 2014
• JLENS to defend D.C. from cruise missiles, drones, airplane threats
For the first time, the U.S. Army lofted a blimp equipped with a new cruise-missile and drone-fighting radar system high above rural Maryland.
 |
JLENS stands for Joint Land Attack Cruise Missile Defense Elevated Netted Sensor System, but the system has proven itself against all types of land, air and sea threats.
Courtesy of Raytheon |
|
The system, made by Raytheon Company (NYSE: RTN) and known as JLENS, consists of two helium-filled aerostats, or tethered blimps, that float 10,000 feet above the ground and carry powerful radars.
 |
JLENS is tethered to the ground by a 1-inch cable and can withstand wind speeds greater than 100 knots.
Courtesy of Raytheon |
|
"JLENS is strategically emplaced to help defend Washington D.C. and a Texas-sized portion of the East Coast from cruise missiles, drones and hostile aircraft," said Dave Gulla, vice president of Raytheon Integrated Defense Systems' Global Integrated Sensors business.
"JLENS can detect potential threats at extremely long ranges, giving North American Aerospace Defense Command more time to make decisions and more space to react appropriately."
 |
JLENS' powerful radar provides 360-degree coverage of an area approximately the size of Texas.
Courtesy of Raytheon |
|
As part of the deployment, Raytheon engineers raised one of the football-field sized aerostats thousands of feet in the air and conducted a series of tests to ensure it was operating as designed.
 |
Sunset view under the belly of the JLENS aerostat.
Courtesy of Raytheon |
|
The company will continue to test and integrate the radar for several more days, then turn the first JLENS balloon over to Soldiers of the U.S. Army's A Battery, 3rd Air Defense Artillery.
 |
JLENS can stay aloft for 30 days at a time and float up to 10,000 feet in the air.
Courtesy of Raytheon |
|
The second aerostat is scheduled to go aloft in early 2015.
Following a series of additional tests, it will also be turned over to the Soldiers, who will conduct an operational exercise with JLENS.
 |
JLENS can stay aloft for 30 days at a time and float up to 10,000 feet in the air.
Courtesy of Raytheon |
|
During the exercise, information from JLENS will be used by NORAD, the U.S.-Canadian organization charged with aerospace warning, aerospace control and maritime warning for North America.
 |
JLENS is tethered to the ground by a 1-inch cable and can withstand wind speeds greater than 100 knots.
Courtesy of Raytheon |
|
The 263rd Army Air and Missile Defense Command, which is responsible for defending the airspace over the National Capital Region, will also use information from JLENS.
 |
JLENS will float high above Aberdeen Proving Ground in Maryland to help protect the U.S. National Capitol Region.
Courtesy of Raytheon |
|
Another JLENS system is in strategic reserve, ready to be deployed anywhere in the world at the request of combatant commanders, should they require comprehensive cruise missile defense capability.
About JLENS
A JLENS system, known as an orbit, consists of ground equipment and an integrated radar system on two tethered, 80-yard aerostats, which fly at altitudes of 10,000 feet above sea level and remain aloft and operational for 30 days.
 |
JLENS will float high above Aberdeen Proving Ground in Maryland to help protect the U.S. National Capitol Region.
Courtesy of Raytheon |
|
This capability better enables commanders to defend against threats including cruise missiles, drones, and aircraft.
JLENS also provides ascent phase detection of tactical ballistic missiles and large-caliber rockets.
 |
One JLENS orbit can provide the same 24/7 coverage for a 30-day period that 5 fixed wing surveillance aircraft provide.
Courtesy of Raytheon |
|
JLENS completed developmental testing in December, 2013.
JLENS has demonstrated its ability to integrate with defensive systems and help Patriot, AMRAAM, NASAMS and Standard Missile 6 intercept cruise missile targets.
 |
One JLENS orbit can provide the same 24/7 coverage for a 30-day period that 5 fixed wing surveillance aircraft provide.
Courtesy of Raytheon |
|
JLENS proved it can detect and track short-range ballistic missiles in their boost phase during a series of tests in 2013.
About Raytheon
Raytheon Company, with 2013 sales of $24 billion and 63,000 employees worldwide, is a technology and innovation leader specializing in defense, security and civil markets throughout the world.
With a history of innovation spanning 92 years, Raytheon provides state-of-the-art electronics, mission systems integration and other capabilities in the areas of sensing; effects; and command, control, communications and intelligence systems, as well as cyber security and a broad range of mission support services.
Raytheon is headquartered in Waltham, Mass., USA.
For more about Raytheon, visit us at www.raytheon.com and follow us on Twitter @Raytheon
Raytheon Company
Integrated Defense Systems
Tewksbury, Mass., USA
Media Contact:
Mike Nachshen
+1.520.269.5697
idspr@raytheon.com
SOURCE Raytheon Company
http://www.raytheon.com/newsroom/
